FEATURES
Delivering performance, reliability and unrivalled comfort. The Pathcross 650-L gives you a premium 2-Up riding experience that will take you through uncharted territory with ease and comfort.
The powerful V-Twin 650cc DHOC motor and CV-Tech clutch system will deliver enough performance for any task. The full size beam chassis features a 3500lbs winch and 4×4 with locking front differential giving you peace of mind to get you out of the toughest situations.
No matter how rugged the terrain gets you can count on the adjustable gas coil over suspension system, and adjustable EPS settings to keep you in total control while allowing you and your passenger to have a smooth comfortable ride. Your passenger will want to ride longer and harder thanks to the premium 2-Up seat configuration, Hand grips and a backrest means you can go Beyond Roads like never before.
TECHNICAL DATA
- 649cc V-Twin Cylinder DHOC ● Liquid Cooled 4-Stroke ● DELPHI Electronic Fuel Injection (EFI) ● Compression Ratio: 10.3:1 ● Power: 53hp-6300RPM ● Torque: 46ft lbs-5300RPM
- CV-Tech CVT Clutch System ● Selectable L/H/N/R/P ● Selectable 2WD-4WD-4WD Front Locking Differential ● Shaft Drive
- Independent Dual A-Arm Front & Rear ● YIT 18 Way Adjustable Rebound/ Compression Gas Coil Over Reservoir Bypass Front Shocks ● YIT 18 Way Adjustable Rebound Gas Coil Over Rear Shocks ● Adjustable Coil Over Spring Rate
- 3 Mode Speed Adjustable Electric Power Steering (EPS)
- Aluminum Alloy Wheels 26×9-R14 Front/ 26×11-R14 Rear ● 26in Tires ● Front/ Rear Duel Vented Disk Brakes With Hydraulic 2 Piston Callipers
- 1588kg Winch ● Synthetic Winch Rope/ Steel Winch Hook
- Overall Vehicle Dimensions: 2.44m X 1.24m X 1.4m ● Wheel Base: 1.5m ● Tire Track Width: 1.02m ● Ground Clearance: 0.28m
- Fuel Capacity: 18.2L ● Rack Capacity: 34kg Front/ 68kg Rear ● Towing Capacity: 334kg ● Passenger Capacity: 2 Person With Backrest And Grab Handles
- LED Headlights And Taillights ● Integrated Turn Signals/ 4-Way Flashers ● Horn ● 12V Accessories Outlet ● USB Ports ● Easy To Read LED Multifunction Display
- Rearview Mirrors ● Wrap Around Hand Guards ● Plastic Skid Plate
- 2in Hitch Receiver With 2in Tow Ball ● Rear Storage Compartment ● Under Seat Storage Compartment
*The price indicated does not include registration fees, taxes or the cost of freight or the installation of the accessories. Photos for illustrative purposes only. Specifications can change. Contact us for more details.
TOP FEATURES
SPECIFICATIONS
649cc V-twin, 53 horsepower
Selectable 2WD-4WD , shaft drive
Front & Rear Independent Dual A-Arm
Adjustable Coilover Shocks
