FEATURES
TECHNICAL DATA
- 649cc V-Twin Cylinder DHOC ● Liquid Cooled 4-Stroke ● DELPHI Electronic Fuel Injection (EFI) ● Compression Ratio: 10.3:1 ● Power: 53hp-6300RPM ● Torque: 46ft lbs-5300RPM
- CV-Tech CVT Clutch System ● Selectable L/H/N/R/P ● Selectable 2WD-4WD-4WD Front Locking Differential ● Shaft Drive
- Independent Dual A-Arm Front & Rear ● YIT 18 Way Adjustable Rebound/ Compression Gas Coil Over Reservoir Bypass Front Shocks ● YIT 18 Way Adjustable Rebound Gas Coil Over Rear Shocks ● Adjustable Coil Over Spring Rate
- 3 Mode Speed Adjustable Electric Power Steering (EPS)
- Aluminum Alloy Wheels 26×9-R14 Front/ 26×11-R14 Rear ● 26in Tires ● Front/ Rear Duel Vented Disk Brakes With Hydraulic 2 Piston Calipers
- 1588kg Winch ● Synthetic Winch Rope/ Steel Winch Hook
- Overall Vehicle Dimensions: 2.23m X 1.24m X 1.35m ● Wheel Base: 1.34m ● Tire Track Width: 1.02m ● Ground Clearance: 0.28m
- Fuel Capacity: 18.2L ● Rack Capacity: 34kg Front/ 68kg Rear ● Towing Capacity: 334kg ● Passenger Capacity: 1 Person
- LED Headlights And Taillights ● Integrated Turn Signals/ 4-Way Flashers ● Horn ● 12V Accessories Outlet ● USB Ports ● Easy To Read LED Multifunction Display
- Rearview Mirrors ● Wrap Around Hand Guards ● Plastic Skid Plate
- 2in Hitch Receiver With 2in Tow Ball ● Rear Storage Compartment ● Under Seat Storage Compartment
TOP FEATURES
SPECIFICATIONS

649cc V-twin, 53 horsepower

Selectable 2WD-4WD , shaft drive

Front & Rear Independent Dual A-Arm

Adjustable Coilover Shocks
