FEATURES
WORK HARD, PLAY HARD. Take your entire family on adventures, or maximise your passenger and cargo capacity on any job site. Our 6-Seat crew cab is designed with strength and comfort in mind.
The powerful 1000cc DHOC motor is paired with the legendary CV Tech clutch system, allowing you to push the limits on the job site or the trails.
The Workcross 1000-6 features a fully adjustable gas coilover suspension system so you can tackle the toughest trails with comfort making this the perfect machine for work and family fun.
TECHNICAL DATA
- 976cc V-Twin Cylinder DHOC ● Liquid Cooled 4-Stroke ● DELPHI Electronic Fuel Injection (EFI) ● Compression Ratio: 10.5:1 ● Power: 85hp-6500RPM ● Torque: 74ft lbs-5500RPM
- CV-Tech CVT Clutch System ● Selectable L/H/N/R/P ● Selectable 2WD-4WD-4WD Front Locking Differential ● Shaft Drive
- Independent Dual A-Arm Front & Rear ● YIT 18 Way Adjustable Rebound/ Compression Gas Coil Over Reservoir Bypass Front Shocks ● YIT 18 Way Adjustable Rebound Gas Coil Over Rear Shocks ● Adjustable Coil Over Spring Rate
- 3 Mode Speed Adjustable Electric Power Steering (EPS)
- Aluminum Alloy Beadlock Wheels 27×9-R14 Front/ 27×11-R14 Rear ● Front/ Rear Duel Vented Disk Brakes With Hydraulic 2 Piston Calipers ● Mechanical Rear Parking Brake
- 1588kg Winch ● Synthetic Winch Rope/ Steel Winch Hook
- Overall Vehicle Dimensions: 3.9m X 1.65m X 1.98m ● Wheel Base: 2.92m ● Tire Track Width: 53in ● Ground Clearance: 12in ● Cargo Bed Dimensions: 133m x 0.91m x 0.29m
- Fuel Capacity: 45.5L ● Cargo Bed Capacity: 453kg ● Towing Capacity: 1133kg ● Payload Capacity: 680kg ● Passenger Capacity: 6 People Double Row 3 Seat Bench With Seatbelts
- Included Features: Scratch Resistant Front/ Rear Polycarbonate Windshield ● Polycarbonate Roof ● Polycarbonate Half Doors ● Side View/ Rear View Mirrors ● Portable Storage Box
- LED Headlights And Taillights ● Integrated Turn Signals/ 4-Way Flashers ● Horn ● 90W Top LED Light Bar ● Interior LED Reading Light
- 12V Accessories Outlet ● USB Ports ● Easy To Read LED Display
- Front/ Rear Steel Powder Coated Bumpers ● Gas Shock Assist Tilting Cargo Bed
*The price indicated does not include registration fees, taxes or the cost of freight or the installation of the accessories. Photos for illustrative purposes only. Specifications can change. Contact us for more details.
TOP FEATURES
SPECIFICATIONS
976cc V-twin, 71 horsepower, 85 N.m
Selectable 2WD-4WD , shaft drive
Front & Rear Independent Dual A-Arm
Climate Controlled Cab (HV); New tempered front and rear windshield design
